Types of Belt Oil Skimmer:
Being as premier belt oil skimmer manufacturers in India, different types are we provided according to different need which are given below.
-
Floating Belt Skimmers: A skimmer that can be adjusted to the changing fluid level through floating on the surface of the liquid.
-
Motorized Belt Skimmers: This works on an electric motor that operates the belt to move automatically and continuously to collect the oil efficiently.
-
Manual Belt Skimmers: These are manually operated, and can usually be used to move a belt, and collect oil off the liquid surface in the form of a crank.
-
Retractable Belt Skimmers: This type has a belt that can be lengthened or shortened to access tanks or sumps to offer flexibility in use.
-
Vertical Belt Skimmers: This is designed in a vertical position, and the belt is allowed to be thrown downwards in the liquid in order to skim the oil.
-
Heavy-duty Belt Skimmers: This is constructed using strong materials, and a powerful drive is used to pump out large volumes of oil in harsh industrial conditions.
-
Flat Belt Skimmers: Belt oil skimmer suppliers in India involves the use of a flat and wide belt to scoop thin layer of oil in a large area of liquid surface.
-
V-belt Oil Skimmers: This utilizes a V-shaped belt, commonly mounted in a deep or narrow sumps, to help the oil to be drawn to it more efficiently on the various sides.
Technical Specification of Belt Oil Skimmer:
We've added below a specialized table of belt oil skimmer in India that provides further technical specification information
| Parameter |
Standard Industrial Models |
Advanced/High-Performance Specifications |
| Oil Removal Capacity |
10 - 100 LPH (Litres per hour) |
Up to 3000 LPH for heavy-duty, high-flow applications |
| Belt Width |
50 mm to 200 mm |
Up to 500 mm for increased surface contact and recovery |
| Belt Material |
Special Oleophilic Polymer, Polyurethane (PU) |
High-Wear Resistance Polymer, Stainless Steel (SS316) for chemical resistance |
| Motor Power |
25 Watts to 0.25 kW |
Up to 2 kW for high-viscosity or high-volume effluents |
| Motor Type |
AC Geared Motor, TEFC (Totally Enclosed Fan Cooled) |
Flameproof (Ex-d) Motor, Variable Frequency Drive (VFD) for speed control |
| Electrical Voltage |
230V to 415V, 50/60 Hz, Single or Three Phase |
Available in various voltages, compatible with automation systems |
| Material of Construction (MOC) |
MS (Mild Steel) Powder Coated, SS304 |
SS316 (for highly corrosive environments), FRP (Fiberglass Reinforced Plastic) |
| Scraper Material |
Teflon, Glass-filled Nylon |
High-performance Ceramics or Engineered Polymers |
| Mounting |
Wall Mount, Floor Stand, Cantilever Pole |
Swivel-arm mast system, Floating pontoon skimmers |
Benefits & Features of Belt Oil Skimmer:
As belt oil skimmer suppliers in India, we provided different benefits according to convenience and market requirement which are given below.
-
High Efficiency: The oleophilic belt substance is selective to the oil and grease and hence the oil removal rate is very high with minimum water pick-up. This will enable successful separation and extraction of useful oils.
-
Manages Varying Levels: Belt oil skimmer manufacturers in India can be used in tanks or sumps where there are varying levels of fluid. The floating or adjustable arrangement helps to have the belt in constant contact with the oil layer.
-
Easy to Install and Build: Our belt skimmers are easy to install and easy to build due to an excellent design with very few moving parts. These need little maintenance which minimizes the downtime and the cost of operation.
-
Cost-Effective Solution: These skimmers will lead to rapid payback because they save and reuse valuable oil, and they save machine damages due to oil contamination. They are an inexpensive remedy to a major industry issue.
-
Small Size: The small size construction means that they can be fitted into the existing industrial installations without significant adjustments. They can easily be attached on machine tanks, sumps or pits.
Applications of Belt Oil Skimmer:
Serve as premier belt oil skimmer manufacturers in India, it is applicable in different sites and centers which are given below.
-
CNC Machine Shops: The most common application of belt skimmers is in the removal of tramp oil in machine tool coolants. Belt oil skimmer suppliers in India prolongs the life of the coolant, preserves cutting tools and enhances quality of the finished part.
-
Wastewater Treatment Plants: This is necessary to remove floating oils, fats, and greases in the industrial wastes and then released into the sewerage. This assists in ensuring the facilities are in compliance with the environment regulations and avoid pollution.
-
Parts Washers and Degreasing Tanks: In this type skimmers are used to clean oil and contaminants of the washing fluid. This makes the fluid not get saturated with oil hence effective cleaning and life span of the solution is guaranteed.
-
Oil Refineries and Petrochemical Plants: These are applied to extract the useful hydrocarbons in wastewater streams and tank farms. This does not only stop the contamination of the environment but also leads to the recovery of recoverable oil.
-
Food Processing Industry: Belt skimmers are best suited to extract animal fats and vegetable oil off water that has been used to make food and also water utilized in sanitation. They assist in sustaining clean processing environments and adherence to hygienic conditions.
Why Choose Us as Belt Oil Skimmer?
-
Designed to work in India: Our products have been made to be very efficient in diverse and sometimes demanding Indian industrial conditions.
-
Quality & Durability: To make our skimmers last longer and have a high operational life, we use the best quality that is corrosion-resistant.
-
Expert Support: Our service offers all-inclusive services during the selection, installation, and maintenance.
-
Custom Solutions: We will be able to offer custom skimmers and settings that perfectly fit your requirement.
Ocean Enterprises is well known belt oil skimmer manufacturers in India and suppliers in India. Itis an important investment in any industry that has to deal with oil-contaminated water. It is an easy, dependable and very productive solution that is shown to save a lot of money by the recovery of oil and by the minimization of the costs of its disposal. Your use of a belt skimmer is a promise to not only the environment but also to enhanced functioning effectiveness. Our solid and low-service model determines them as a reliable workhorse to be used in the long term. We have the most competitive price point with the best quality of products to invest. Contact Us for more details.
